PNEUMETIC CYLINDER
GRI MODEL SD-20 SERIES
DESCRIPTION
Giriraj industries Make “GRI” Model (M.S. Tube & Tie Rod) Heavy Duty Pneumatic Cylinders.
-
Double Ended
-
Single Acting. N/O, N/C
-
Double Acting.
-
Magnetic
TECHNICAL DATA:
Bore (mm):80/100/125 l 150 l 200 l 250 l 300 l 350 l 400 l 450
Piston Rod (Ø):25//25/032 l 032 l 038 l 051 l 051 l 063 l 063 l
Stroke:75mm to 1000 mm (Up to 2000mm)
Tube: M.S. Tube (M.S. Seamless Tube with Hard Chrome Plated )
End Cover:C.I.GRADE 25
Seals:Buna – N / P.U. / Hi - Nitril (Viton on Request)
Temperature:80°C / 100°C / 180°C Max.
Pressure:Up to 12 Bar
Mounting:Center Trunnion Mounting, Pivot Mounting, Eye Rod Mounting, Fork Mounting, Center Lug Mounting, Center Trunnion Mounting (Adjustable), Pivot Bracket & Pin Mounting, Flange Mounting, Front/Rear Trunnion Mounting (Fixed), Front/Rear Fixed Trunnion MountingTOP, Foot Bracket Mounting, Center Trunnion Mounting (Adjustable)
